Re: Jagdpanther no 13

Post by David Brady »

Thanks guys, next up add the welds on the starter plate and some on the rear of the hull, I'm probably done on the back until I get some access covers then I can mount the tools and other remaining details.
Yesterday's progress, I finished the welds  off today
Yesterday's progress, I finished the welds off today

David Brady
Posts: 541
Joined: Fri Aug 29, 2008 5:04 pm
Location: Seaford East Sussex
Has liked: 55 times
Been liked: 419 times

Re: Jagdpanther no 13

Post by David Brady »

Hi All

Steve Winstone jacking block fitted, also partially cut through the side running boards to simulate individual pieces.

Regards
David
Attachments

simon_manning
Posts: 1894
Joined: Fri Nov 02, 2007 8:51 pm
Location: new forest,hampshire,u.k.
Been liked: 1251 times

Re: Jagdpanther no 13

Post by simon_manning »

coming together nicely Dave, Having the Parts made and ready to fit is such a Luxury, Keeps the interest constant and a massive time saver, keep at it , regards simon.

mark lawson
Posts: 626
Joined: Tue May 14, 2013 9:14 pm
Location: Solihull
Has liked: 1858 times
Been liked: 291 times
Contact:

Re: Jagdpanther no 13

Post by mark lawson »

Masters are ready they are designed as the original to lock into place on the rear plate, they will be going away for casting this week

Werkstatt - 5, 1/6 Panzer parts. werkstatt.five@gmail.com
RAG Militärmodellbau
IG Militärmodellbau

David Brady
Posts: 541
Joined: Fri Aug 29, 2008 5:04 pm
Location: Seaford East Sussex
Has liked: 55 times
Been liked: 419 times

Re: Jagdpanther no 13

Post by David Brady »

Hi Mark,

They look wonderful, two sets please.

Cheers

David Brady
Posts: 541
Joined: Fri Aug 29, 2008 5:04 pm
Location: Seaford East Sussex
Has liked: 55 times
Been liked: 419 times

Re: Jagdpanther no 13

Post by David Brady »

Hi All

Not to much done lately due to another project, redone some welds on the back, had a trip out to Steve's last weekend and he kindly machined the inner rims for me so I could add the detail bolts, after lots of drilling,sanding, the job was done.
Unmodified
Unmodified
Modified
Modified
Regards
David

Gary Phillipson
Posts: 24
Joined: Tue Feb 18, 2020 5:45 pm
Has liked: 1 time
Been liked: 8 times

Re: Jagdpanther no 13

Post by Gary Phillipson »

Love the details on those wheels nice one.👍

graham pipe
Posts: 39
Joined: Fri Oct 01, 2010 8:00 pm
Has liked: 2 times
Been liked: 13 times

Re: Jagdpanther no 13

Post by graham pipe »

Hi Dave, stunning work as usual. Love the detailing on those wheels! However, it's such a shame that when this kit was released back in 2004 (or whenever and prior to Kian and Monique taking the helm) there was a serious inaccuracy inasmauch as the wheels only have 20 bolts rather than the 24 on later Panthers and all JP's. As I'm sure you know, the first production Ausf D Panthers had only 16 wheel rim bolts which were then upgraded with reinforcing rivets 'twixt the bolts to overcome in the field failures.

I'm fully conversant with Panther wheels having restored all 32 for Mike Gibb's Weald Foundation (previously the SdKfz Foundation) Jagdpanther. My 32 times tables came in handy when calculating the number of bolts, period type Nyloc nuts. conical spring washers and the special U shaped bolt head locking tabs which I had laser cut then folded on a brake press using a custom press tool. Here are some photos of the before, during and after stage.

Myself
In the beginning - 50 wheels to make 32..
In the beginning - 50 wheels to make 32..
In the beginning - 50 wheels to make 32..
In the beginning - 50 wheels to make 32..
, I am almost finished with a new build JP which is 95% Armortek parts sourced from this Forum, kind fellow modellers and from Monique's extensive stock of spares. All told, it's been a somewhat expensive way of creating a JP but the end result has been well worth it. Will start a thread of the build on this Forum quite soon.

Anyway, keep up your excellent work - you're a true inspiration to all of us.
Attachments
About to load my van with 16 of the critters
About to load my van with 16 of the critters
The first 6 ready for delivery
The first 6 ready for delivery
JP (9).jpg
JP (9).jpg (41.23 KiB) Viewed 591 times
JP (8).jpg
Masked for priming
Masked for priming
Gas cutting necessary on many bolts
Gas cutting necessary on many bolts
A fair bit of rust and crud...
A fair bit of rust and crud...
Getting them apart
Getting them apart

David Brady
Posts: 541
Joined: Fri Aug 29, 2008 5:04 pm
Location: Seaford East Sussex
Has liked: 55 times
Been liked: 419 times

Re: Jagdpanther no 13

Post by David Brady »

Hi Graham

To be honest I did not know the number of bolts on early or late Panthers, your information is very interesting, and thanks for the kind comments, some are blessed with great talent, my skill is perseverance, 21 years later I'm still trying to get one together.

Look forward to seeing your build

Regards
David
